Pipe solutions
- Trenchless rehabilitation technology. NO DIG. NO DAMAGE. NO MESS.
- Non-invasive quick repairs. Short sections or entire piping system.
- Trenchless technology (Lining and bursting methods) allows us to rehabilitate the pipe from one or two small access points.
- Minimal disruption to daily operations.
- Coating of lined or unlined pipes – from a small section to an entire piping system.
- Pipe relining that is resistant to corrosion and root infestation as well as ground movement.
- Tried and tested technology resistant to chemicals, corrosion, ground movement and external intrusion into pipe system.

See our pipe solutions in action!
Descaling
Pipe cleaner navigating multiple bends
Removing grease and scale
Pipe relining
Imagine having a broken/leaking/blocked pipe to your premises or business that was buried under gardens or concrete. Reaching and then replacing this pipe is difficult and very disruptive. Now imagine if you were able to simply repair this underground damage without having to dig up.
Traditionally, fixing drains that are broken in an obstructed area required a team to dig up the area, remove the pipes and replace them with new sections. This is not only costly, but also very time consuming and disruptive. Not to mention the revenue that would be lost if you had to close your doors until this work was completed.
IDS provides a better, more cost effective, quicker solution – pipe relining. Pipe relining can repair damaged pipes without the need to excavate trenching the surrounding areas. Broken, cracked & root infected drain pipes can be repaired without the need for invasive digging and replacement by using the latest technology.

Our relining and coating products
Picote Brush Coating™
- The Picote Brush Coating™ System is a resin coating that is “spin” brushed onto the interior of the pipe.
- It is a simple, fast and practical coating system used for drain and sewer renovation.
- It is able to coat unlined or lined pipes or connections from DN32 - DN200 / 1¼" - 8".
- Coat anything from a small area (such as a lined connection) to entire piping systems, for example blocks of flats, using the Picote Smart Mixer and dual-colour 100% solids epoxy resin cartridges for cast iron, PVC, concrete or clay pipes.
BRAWOLINER®
- The BRAWOLINER® product is applied as a resin impregnated sock liner that is introduced or injected into the pipe.
- BRAWOLINER® is a concept that provides long-lasting protection and rapid assistance in the area of sewerage rehabilitation systems.
- Thanks to a special loop construction all BRAWOLINER® is extremely flexible. This makes it the perfect solution for defective pipes containing multiple bends of up to 90° and up to two changes in diameter.
- With a working life of over 50 years, BRAWOLINER® is a clean, economical and environmentally-friendly alternative to expensive and time-consuming excavation works.
Fernco Pipe Doctor
- A cost effective and easy to use solution for the permanent and watertight repair of damaged pipes, without the need for excavation work.
- High performance, no dig pipe repair solution.
- The system can be used to repair pipes of 70-560mm diameter or larger.
- Installed internally and eradicates need for costly, disruptive and time consuming excavation work..
- Solution available for damaged pipe that has a 90 degree bend.
Looking for a long-term solution?
Damage to pipes, particularly underground pipes can be costly to repair. IDS is able to conduct a trenchless assessment of the health of your pipes and provide a comprehensive report of the overall state of your piping system. Based on the report we identify damage and weak spots and carry out preventative relining and coating of your system.
